LED-75P735 TCL 75" UHD GOOGLE TV

Product Overview

• Edgeless Screen
• Metallic Finish
• Slim Design
• Two Leg Stand
• 4K WCG（90% DCI-P3）
• D-LED
• Dolby Vision
• MEMC 60HZ
• HDR 10
• Dolby Atmos
• DTS-HD
• 15W*2 (75”)
• Google TV
• Google Assistant
• Hands-Free Voice Control
• Optional Camera/Video Chat
• Health Hub
• Google Duo
• Game Bar/Game Mode/ALLM
• Google Apps
• Google Chromecast
• CPU: CA55*4 @1.3GHz max
• GPU: G31 MP2, 800Mhz
• Memory: 2GB DDR + 16GB Flash
• HDMI
• USB3.0, USB 2.0
• WiFi (2.4G+5G Dual-band)
• Bluetooth 5.1

Warranty Term

• 2 Years


• Display Resolution: 3840×2160
• Video Processing: G31x2 800MHz
• Backlight Module: Direct LED
• Live Colour: HDR10, Dolby Vision
• Deep Color: Micro Dimming (1296 zones)
• Intelligent Image Enhancer: AIPQ Engine
• Viewing Angle: 178/178
• Screen Format: 16:9, 4:3, Cinerama, 14:9 zoom, 16:9 zoom, 16:9 zoom up
• Picture Mode: Dynamic, Standard, Smart HDR, Sport, Movie (Game, PC)

AUDIO

• Bluetooth Audio: Bluetooth 5.1
• Sound Output: 2 x 15W
• Speaker Type: Integrated speaker Box (Bottom Side)
• Sound Mode: Standard, Dynamic, Movie, Music, Voice, Game, Stadium
• Sound Enhancer: Dolby Audio, DTS-HD
• S-Force: Dolby Atmos
• Dolby: Dolby Audio (MS12Z), DTS-HD

TERMINALS

• HDMI: x3 (Arc/eArc,1.4,2.1)
• USB 2.0: USB 3.0 x1, 2.0 x1
• Ethernet Connection: yes x1 (RJ45, 10/100M)
• Composite Video Input (s): yes x1 AV Input (Adapter)
• RF Connection Input(s): yes x1
• Digital Audio Output (s): SPDIF (Optical)
• Audio Out: Yes (Headphone)
• Headphone Out: Yes

• Wifi: 2.4GHz/5GHz dual-band Wi-Fi 802.11 b/g/n 2T2R
• Web Browser: BrowseHere
• Video Search: BrowseHere, Netflix, Youtube
• Media remote: MagiConnect
• Mobile to TV - Mirroring, DLNA: Google Chromecast, MagiConnect, T-Home

GENERAL

• Power Requirements: AC 100V-240V 50/60Hz
• Power Consumption: 250W
• Dimension (WxHxD) mm with Stand: 362 x 1023 x 1668
• Dimension (WxHxD) inches with Stand: 14.25 x 40.27 x 65.66
• Dimension (WxHxD) mm without Stand: 91.8 x 959 x 1668
• Dimension (WxHxD) inches without Stand: 3.61 x 37.75 x 65.66
• Weight with stand (kg): Approx. 21.8
• Weight without stand (kg) : Approx. 21.3
• Package Dimension (W X H X D) mm 255 x 1168 x 1850
• Package Dimension (W X H X D) inches 10.03 x 45.98 x 72.83
• Gross Weight (kg): 33

What's in the box

• Operation Manual, Remote Control and Battery, Base Stand, AC Power Cord, Wall Bracket, Warranty Card
