Description
Product Overview
- Portable party speaker
Warranty Term
-
Parts: 1 Year
-
Labor: 1 Year
General Specifications
-
Transducers: 2 x 5.25inch(133mm) woofers, 2 x 2.25inch (57mm) tweeters
-
Output power: 160 W RMS (IEC60268)
-
Power input: 100 - 240 V ̴ 50/60 Hz
-
Frequency response: 40 Hz - 20 kHz (-6dB)
-
Signal-to-noise ratio: > 80dB
-
Battery type: JBL BATTERY200 Li-ion polymer 34 Wh (equivalent to 7.2V / 4277mAh)
-
Battery charge time: 3.5 hours (speaker off mode)
-
Music play time: up to 12 hours (varies by volume
level and audio content) -
Cable type: AC power cable (type varies by regions)
-
Cable length: 2.0 m / 6.6 ft
-
USB charge out: 5V / 2.1A (Max) (speaker off mode)
- USB format: FAT16, FAT32
- Supported formats: .MP3, .WAV, .WMA, .FLAC
- Product dimensions (W x H x D): 288.4 mm x 570 mm x 297 mm / 11.35” x 22.44” x 11.69”
-
Net weight: 11.05kg / 24.35 lbs
-
Packaging dimensions (W x H x D): 340 mm x 617 mm x 369mm / 13.4” x 24.3” x 14.5”
-
Gross weight: 14.1kg / 31lbs
- Color: Black
Bluetooth
-
Bluetooth® version: 5.4
-
Bluetooth® profile: A2DP V1.4, AVRCP V1.6
-
Bluetooth® transmitter frequency range: 2.4 GHz -2.4835 GHz
-
Bluetooth® transmitter power: ≤ 18 dBm (EIRP)
-
Bluetooth® transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
Input Sensitivity
-
Aux-In: 370mV RMS (3.5mm connector)
-
Mic-In: 20mV RMS
-
Guitar-In: 100mV RMS
- Bluetooth/USB input: -9dBFS
What's in the box:
- 1 x JBL PartyBox Club 120
- 1 x Quick-start guide
- 1 x Safety Instruction and Warranty Card
